Vintage SANSUI Model 2000 Solid State Stereo Tuner Amplifier - $300 (Longmont)
QR Code Link to This Post
This is a vintage 1969 solid-state stereo receiver is fully working and sounds great.
This unit is a tank! Key features include individual bass and treble controls, a loudness function, low and high filters, and phono inputs (specifically for vinyl). It offers excellent RF protection and a high-quality tuner, making it a well-regarded and desirable piece of vintage audio gear with superb warm analog sound.
$300 cash and this price is ultra firm.
Sorry. No deliveries, AC cord included but no speakers nor speaker wires.
SPECS:
General
• Manufacturer: Sansui
• Model: 2000
• Type: Receiver
• Years of manufacture: 1967 - 1969
• Made in: Japan
• Color: silver, housing walnut
• Remote control: no
• Power consumption:
• Dimensions: 415 x 124 x 331 mm (WxHxD).
• Weight: 12 kg
• Original price approx.: 1'595 DM
• Surcharge housing walnut: 115 DM
• Surcharge housing sanding varnish white: 125 DM
Connections
• Number of inputs:
◦ Phono MM: 2.2 mV
◦ Tape Head: 2,0 mV
◦ Tape Play: 150 mV / 50 kOhm
◦ Tape Play DIN: 150 mV / 50 kOhm
Aux: 150 mV / 50 kOhm
◦ Antenna (FM: 75, 300 Ohm, AM).
• Number of outputs:
◦ Tape Rec: 200 mV
Tape Rec DIN: 35 mV
◦ Headphones (6,3mm jack)
◦ 2 pairs of loudspeakers
Technical Data
Amplifier
• Continuous power (at distortion):
◦ 8 Ohm:
◦ 4 Ohm: 2x 36 W
• Dynamic power:
◦ 8 Ohm:
◦ 4 Ohm: 2x 50 W
• Total harmonic distortion: < 0.8
• Attenuation factor: 24 (at 8 Ohm)
• Frequency response:
◦ Phono: 30 - 15,000 Hz, ± 0.2 dB
◦ High Level: 20 - 40,000 Hz (+0 dB, -1 dB)
• Signal-to-noise ratio:
◦ Phono: 70 dB
High Level: 75 dB
• Tone control:
◦ Bass at 100 Hz: ± 10 dB
Treble at 10 kHz: ± 10 dB
• Loudness: yes, +6 dB at 100 Hz, +3 dB at 10 kHz
• Low Filter: yes, 6 dB / octave at 30 Hz
• High Filter: yes, 6 dB / octave at 8 kHz
• Mute: yes
Tuner
• Reception: FM/MW
• Frequencies:
◦ FM: 88 - 108 MHz
◦ MW: 535 - 1605 KHz
• Input sensitivity:
◦ FM: 1.8µV
◦ MW: 15µV
• Frequency response: 30 - 15,000 Hz (+0.2/-0.5 dB)
• Distortion factor:
◦ FM (1 kHz): < 0.10% (mono), < 0.15% (stereo).
• Signal-to-noise ratio:
◦ FM (65 dBf): 75 dB (mono), 66 dB (stereo).
◦ MW: 55 dB
• Channel separation: 35 dB (1 kHz)
• selectivity: 50 dB
• Co-wave selection: 2.7 dB
• Spurious wave selection:
◦ FM: 80 dB
• Mirror frequency attenuation:
◦ FM: 90 dB
MW: 40 dB IF attenuation:
◦ FM: 110 dB
◦ MW: 40 dB
• AM suppression: 55 dB
Special Features
• Mono / Stereo switch
